Home > Products > PHYSICS > Electric meters

P01027, 220 Series Clamp Meter

MODEL	(UT-221)	(UT-222)
Function	Measuring range	Measuring range
DCV	400mV/4V/40V/400V/600V±(0.7%+2)	400mV/4V/40V/400V/600V±(0.7%+2)
ACV	400mV/4V/40V/400V/600V±(1.5%+5)	400mV/4V/40V/400V/600V±(1.5%+5)
DCA	400A, 600A ±( 1.5%+7)	400A, 600A ±( 1.5%+7)
ACA	400A, 600A ±( 1.9%+7)	400A, 600A ±( 1.9%+5)
Resistance	400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ ±(0.9%+3)	400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ ±(0.9%+3)
Max open angle	45 mm
Power	9V, 6F22
Dimension	208 x 82 x 41 mm
