Home > Products > PHYSICS > Electric meters

P01022, Model 39 Series Digital Multimeter

MODEL	(UT-39A)	(UT-39C)
Function	Measuring range	Measuring range
DCV	200mV/2V/20V/200V/1000V±(0.5%+1)	200mV/2V/20V/200V/1000V±(0.5%+1)
ACV	2V/20V/200V/750V±(0.8%+3)	2V/20V/200V/750V±(0.8%+3)
DCA	20uA/200uA/2mA/20mA/200mA/10A ±(0.8%+1)	2mA/ 20mA/20A±(0.8%+1)
ACA	200uA /20mA/200mA/10A±(1%+3)	2mA/ 20mA/20A±(1%+3)
Resistance	200Ω/2kΩ/20kΩ/200kΩ/2MΩ/200MΩ ±(0.8%+1)	200Ω/2kΩ/20kΩ/2MΩ/200MΩ ±(0.8%+10)
Capacitance	2uF±(4%+3)	2nF/200nF/20uF±(4%+3)
Frequency		2KHz~20KHz±(1.5%+5)
Temperature		-40℃~1000℃±(2%+8)
LCD size	61 x 32 mm
Diode test	YES
Power	9V, 6F22
Max. Display	1999
Dimension	172 x 83 x 38 mm
